PB-EMT3-18 – 45° ELBOW
| 45° ELBOW | ||||||||||
| CODE | DIA. | A | B | PACKAGE / PIE. | ||||||
| PB-EMT3-18-15 | 1/2” | 18 | 54,00 | 100 | ||||||
| PB-EMT3-18-20 | 3/4” | 23 | 69,00 | 100 | ||||||
| PB-EMT3-18-25 | 1” | 29 | 87,00 | 50 | ||||||
| PB-EMT3-18-32 | 1-1/4” | 38 | 114,00 | 25 | ||||||
| PB-EMT3-18-40 | 1-1/2” | 44 | 132,00 | 10 | ||||||
| PB-EMT3-18-50 | 2” | 55 | 165,00 | 5 | ||||||
Pressure Class: Steel
Installation Temperature: -25 °C / + 90 °C
Installation Type: To allow the 45° connection of two rigid conduit, protection degree IP 40
In accordance with: UL 514B
Colors
